238T Metal-over-Metal Roof Recover Systems

238T Metal-over-Metal Roof Recover Systems

McElroy Metal’s 238T Metal-Over-Metal recover systems are an ideal solution for metal roofs at the end of their service life.

As the name implies, recover systems enable a new metal roof to be installed over an existing roof, eliminating costly and problematic tear-off and disposal of the old roof.

McElroy’s recover systems provide a long-term solution at a cost that is competitive with single-ply recover while lasting two (2) to four (4) times longer.

View Related Files Build a Submittal Package

Read Metal Roofing Magazine Article

Click image to enlarge

Great for

Walls

Walls

Roofs

Roofs

Residential

Residential

Commercial

Commercial

Advantages of Recover vs. Replacement

icon-checkmark_red

50-60 year Service Life

icon-checkmark_red

Minimal Occupant Disruption

icon-checkmark_red

Individual Panel Replaceability

Extremely High Uplift Capacity

Long Length Panels Eliminate Leak Prone Panel Laps

Onsite Rollforming & 24" Wide Panels Reduce Labor

Onsite Rollforming Minimizes Damage, Storage Requirements & Debris

Original Building Design Protected

Multi Span Clips Offer Unparalleled Uplift

Helpful Videos

238T Metal Over Metal Recover

238T Metal Over Metal Recover

Roof Hugger

Roof Hugger is the best way to recover a through fastened or standing seam roof on open framing because the notched sub purlin increases the load carrying capacity of the original purlins.

High floating standing seam systems can be accommodated with special roof huggers and fasteners.

Tall Clip

The tall clip recover system is designed to be installed over existing panels up to 1.5" tall, such as R-Panel.

The system utilizes tall clips that sit between the ribs of the existing panel and attach directly to the purlin below. Insulation fills the the air space between the two roofs.

Hat Over Zee Clips

The hat over zee clip system is an economical alternative to notched purlin for existing exposed fastener or low floating standing seam over open framing retrofit applications.

The two piece system allows for up to 6" of insulation between the two roofs. Optionally, the air space can be ventilated.

Infill with Rigid Insulation

The infill approach is used when retrofitting standing seam panels installed over a solid deck. It also works well on existing exposed fastener or low floating standing seam installed over open framing.

Continuous insulation is one of the biggest benefits of this approach.

Options

Single Ply vs. Metal Recover

Before covering an existing metal roof with single-ply, it's important to consider how that decision impacts the structural integrity of the building.

Whether you're a building owner, design professional, or contractor, the third-party articles below highlight critical issues and engineering considerations that bear serious consideration.

Need help?

Meet Charlie, Our Recover Specialist

Set up a Meeting Now

Charlie-Smith



Before and After

Related Files

Specifications

Metal Panel Care & Maintenance

Product & Trim Information Books

English Installation Manuals

Retrofit & Recover Systems

Product Approval Report / Miami-Dade Notice of Acceptance (NOA)

Product Approval Report / ICC-ES Approvals

Technical Bulletins / Miscellaneous Testing

Get A Submittal Package

238T - 16"
Customize (Recommended)

Customize your submittal package 238T - 16"

Click on your desired documents below to select them for your package.

General Product and Warranty Information

Panel Load Tables w/Section Properties and Testing

Safety Data and Material Safety Data Sheets

238T - 18"
Customize (Recommended)

Customize your submittal package 238T - 18"

Click on your desired documents below to select them for your package.

General Product and Warranty Information

Panel Load Tables w/Section Properties and Testing

Safety Data and Material Safety Data Sheets

238T - 24"
Customize (Recommended)

Customize your submittal package 238T - 24"

Click on your desired documents below to select them for your package.

General Product and Warranty Information

Panel Load Tables w/Section Properties and Testing

Safety Data and Material Safety Data Sheets

Weathertightness Warranties
Weathertightness Warranties

If your project requires a Weathertightness Warranty and you don’t already have a job specific Pre-Approval Form issued by McElroy Metal, click the button below to get started.

See Warranties →

Shop Drawing Service
Shop Drawing Service

Running short of time to complete your own shop drawings? McElroy Metal can help. Click the button below to provide us some basic information and we’ll be in touch soon to discuss your project specifics.

Contact Us →

Download Shop Drawings
Download Shop Drawings

If you’re creating your own shop drawings, click the button below to gain full access to our CAD and PDF Files.

View Drawings →

Find a Distributor/Contractor Near You

Whether you’re building a new home or planning renovations, a metal roof can deliver long-term cost savings and comfort. To explore your options and find the product that meets your aesthetic and budgetary needs, contact a McElroy Metal distributor or contractor in your area today. We can’t wait to help make your dream home a reality.
