Metal Soffit and Fascia Panel

What is Metal Soffit and Fascia?

For some designers and building owners, soffit and fascia material is nothing more than a way to keep birds, insects and mother nature from entering the building and a means to successfully ventilate the structure.

For others however, the fact that soffit and fascia material are responsible for the aesthetic transition from the roof to wall cladding mean the decisions merit serious design consideration.

Regardless of which camp you're in, McElory Metal has a complete line of soffit and fascia panels to meet your needs.





Metal Soffit and Fascia Panel

Advantages of Metal Soffit and Fascia

icon-checkmark_red

With options ranging from flush panels to the more traditional V-groove soffit, our various profiles offer greater design flexibility.

icon-checkmark_red

Solid and vented panels can be combined to meet your specific building requirements with net free area ranging from 2%-10%

icon-checkmark_red

With anticipated lifespans of 50 + years building owners benefit from long-term performance.

icon-checkmark_red

Whether you're looking for a color to match or serve as an accent, we've got you covered. And in most cases enjoy the protection of our 30 year finish warranty.

icon-checkmark_red

Steel panels offer greater spanning capability between supports than other products like aluminum or vinyl.

icon-checkmark_red

Single vendor approach for roofing, walls, soffit and fascia simplifies the building process.

Metal Soffit and Fascia Panel



McElroy offers three distinct profiles to meet design and performance requirements.  From flush panels in different widths, reveal options, various pan profiles and venting capabilities we have the options you're looking for.

Metal Soffit and Fascia Panels
  • FW Panel – FW Panel is a 1 1/2" deep flush metal panel designed for use in vertical and horizontal applications. Available 12" panel width options include: vee grooves, inverted plank, reveals of up to 3", or a traditional smooth appearance. Regardless of the pattern, the 1 1/2" depth and the tongue-and-groove engagement remain the same.
  • Matrix – Matrix soffit panels add an elegant touch to any commercial or residential project. Matrix is available in 12 and 16 inch widths and in colors that match McElroy's wall and roof panels.

    The Matrix soffit system will add an elegant touch to any commercial or residential project. Matrix is available in a wide variety of gauges with Silicone Modified Polyester (SMP) and Kynar 500® (PVDF) colors.
